// OpenWell Submersible Pumps //

Features:

Noise free Operation

Maintenance free

Lower Power Consumption

Long Lasting Life

Application:

Hotels, Hospitals & Apartments

Gardening & Fountain

Domestic & Minor Irrigation

MSO-S1025

MSO-S525

3HP OpenWell 3PH

Performance chart:

Model No	H.P	Pipe Size In mm		H - Head In Meters
Model No	H.P	SUC.	DEL.	Q Discharge in LPH	10	12	14	16	18	20	22	24	26	28	30
MSO-S525	0.5	25	25		7080	6900	6000	5700	4980	3840	*	*	*	*	*
MSO-S1025	1.0	25	25		*	*	11100	10500	9240	8520	7080	6540	5460	2880	1080

MITHILA PUMPS PVT LTD, established in Ahmadabad, (Gujarat) in 1983 for BOREWELL & OPENWELL submersible in 2001 MONOBLOCK series Coimbatore, (TAMILNADU).
